SG600 SwingGate ADA

Modern Motorized Pedestrian Gate

A true complement to your interior design, the SG600 motorized pedestrian gate features a seamless and modern aesthetic. This ADA-compliant handicap gate provides bi-directional access with completely touchless operation. Each SG600 swinging barrier is driven by a quick and energy-efficient motor to provide smooth, quiet, and extremely precise movement. On top of that, the SG600 features an electromagnetic toothed coupling to prevent barriers from being pushed open forcibly. This modern motorized gate also integrates easily with virtually all access control systems via a momentary dry contact and can be configured to your choice of one directional access or bi-directional access. Coupled with a dedicated fire system input, the SG600 is a breeze to install and integrate with existing systems. Being a handicap entry option, the SG600 is built with safety in mind. The SG600’s drive system operates with low impact forces for maximum personnel safety.

Product Benefits

  • Motorized touchless operation
  • Premium styling creates a modern, sophisticated look
  • IP54 enclosure rated
  • Rated for 10,000,000 open and close cycles
  • Numerous customizations including alternate post finishes, custom barrier widths and heights, barrier etching
  • One or two-way swing (motorized)
  • 2 units can be installed together in “saloon style”‘
  • Matches our SL1000 optical turnstile

SG600 SwingGate ADA PDF Downloads

category SG600 Motorized ADA Gate Brochure

category SG600 Motorized ADA Gate Dimensions

category SG600 Motorized ADA Gate Architectural Specifications

Want to Specify This Product? Contact Us Today to Gain Access to Our Specifications and Submittal Packages!

Need Installation?

Hayward Turnstiles has a nationwide network of partner installers. Our team is happy to coordinate installation with one (or multiple) of our certified installers who will handle the purchasing, installation, and integration of turnstiles and gates for you. One point of contact. One comprehensive warranty. One goal: complete project satisfaction.

Contact Us to Begin Your Project!



Applications

Applications:

The SG600 is one of our most premium handicap gate options both in functionality and appearance. This motorized pedestrian gate is perfect for providing handicap entry at any location where aesthetics are equally as important as entrance security. Along with looking great, the SG600 also provides top-notch usability; this motorized swing gate can be operated completely hands-free to provide a completely touchless entry solution. The SG600 integrates easily with virtually all access control software and hardware via a momentary dry contact, allowing you to integrate your SG600 swing gate however you please. Office lobbies, hotels, high-rise apartments, campuses, and more all benefit from the ADA compliant functionality and enhanced, modern design of the SG600 motorized ADA gate.

On top of acting as a great handicap entry solution, 2 of our SG600s can be installed in a tandem or “saloon style” configuration (where they are installed facing each other) to create a wider passage. When setup in this manner, our SG600 saloon style ADA gates provide a clear opening width more than double the opening width of just installing one gate. This saloon style orientation is perfect for an entrance where you want to receive large deliveries, have bulky materials going in and out of your turnstile array regularly, or if you need to let large crowds in at once during events or emergency egress situations.

Specs

Price Range

Premium Value

Post Styling

Polyurethane Post (custom colors available)

Barrier

Tempered Glass

Barrier Height

38" Standard, Optional 47" High Barrier

Standard Barrier Width

36" (custom barrier widths available)

Saloon Barrier Width

74" (when installed with factory recommended 2" gap between swinging panels)

Custom Barrier Width(s)

Barrier Widths can be Customized to Meet Project Requirements

ADA Compliant

Yes

Swing Direction

One-Way or Two-Way

Closing Type

Motorized

Mount Type(s)

Direct Mount or Baseplate Mount (for when you cannot bolt into the ground or run wires from below)

Exterior/Interior Use

Interior/ Exterior covered

Signage

Custom Barrier Etching Available

Details

SG600 SwingGate Motorized ADA Details

Design & Construction:

  • External post fabricated from durable polyurethane
  • Custom colors available
  • Tempered glass barrier with custom sizes available
  • Integrates with virtually all access control
  • Rated for 10,000,000 opening and closing cycles
  • IP54 enclosure rated

Specifications:

  • 36″ ADA compliant opening
  • One-Way 90-degree swing or two-way 180-degree swing
  • Center rotating column
  • Hands-free motorized operation for opening & closing
  • Operates without stop post (no post required)
  • 110-240VAC, 50/60Hz power supply

Warranty:

Units are warranted against defects in materials and
workmanship for a period of one year from date of delivery.
See warranty information for specific details.

Options

SG600 SwingGate Motorized ADA Options

Options:

  • Custom colors available
  • Custom barrier sizes are available
  • Optional high barrier height of 47″ from the floor available
  • Barrier etching is available, contact us for requirements
  • Alternate barrier materials

Dimensions

SG600 SwingGate Motorized ADA Dimensions

PDF

SG600SwingGate Motorized ADA PDF Downloads

category SG600 Motorized ADA Gate Brochure

category SG600 Motorized ADA Gate Dimensions

category SG600 Motorized ADA Gate Architectural Specifications



*Architects and specifiers should contact us for submittal packages, installation manuals, and more information about this product.
